Thermocouples and RTDs with Flange thermowell

Thermocouples and RTDs with Flange thermowell adopt an integral flange fixed structure, which is evenly locked and fixed by multi-point bolts. The contact surface is close, the force is even, and the installation rigidity is extremely strong. It completely solves the pain points of threaded connections that are prone to loosening, falling off, and temperature measurement deviation due to long-term vibration. It can be adapted to severe working conditions such as strong vibration of equipment, high-speed media erosion, and airflow impact for a long time. There is no looseness or displacement during the entire operation. The temperature measurement point is stable. It is suitable for 24-hour continuous industrial production scenarios, and its stability is far superior to conventional threaded installation structures. The flange contact surface is equipped with a high-strength sealing gasket. The sealing coverage is wide, the pressing force is uniform, there are no leakage dead corners, and the pressure resistance is excellent. It can be stably adapted to medium-high pressure and high-pressure industrial conditions, and effectively eliminates safety hazards such as high-pressure medium leakage, air leakage, material leakage, and pressure relief.
Flange connection thermocouple: temperature measurement range -20℃~1600℃, ultra-wide temperature range, high temperature resistance, thermal shock resistance, resistance to high and low temperature sudden changes, fast thermal response, specially adapted to high-load and high-temperature working conditions such as industrial high-temperature kilns, cracking equipment, high-temperature flue gas, and heat treatment.
Flange-connected thermal resistor: temperature measurement range -50℃~600℃, high linear precision of resistance value, good repeatability, and extremely low temperature drift. It focuses on fine constant temperature control of medium and low temperatures, normal pressure and high pressure, and is suitable for production scenarios with extremely high requirements for temperature measurement accuracy and process stability.
It supports a full range of national standard flange specifications such as DN15, DN20, DN25, DN40, and DN50. It is compatible with various structures such as plate flat welding, butt welding flanges, and loop flanges. It is suitable for temperature measurement of large-diameter and large-volume equipment such as large industrial pipelines, vertical storage tanks, large reactors, and kiln cavities.
